SMB/SB Installation and Maintenance Manual 140-11000 • July 20034-5
Flow Control Division
Limitorque Actuation Systems
Table 4.3 – Two-Train Geared Limit Switch – Parts List
Piece Quantity320-2 Description 42
11 Cartridge
21 Drive Sleeve and Shaft
31 Drive Pinion
41 Drive Pinion (Secondary)
51 Declutch Spring
62 Bushing
71 O-Ring
81 Pin
91 Groove Pin (
1
/8"x 1" Long)
10 1 Washer
11 1 Oil Seal
41 1 Gear Frame
42 2 Intermittent Gear Shaft
43 2 Intermittent Pinion Shaft
44 2 Geared Limit Frame Cover
45 8 Intermittent Gear
46 6 Intermittent Pinion
47 2 Stem Spur Pinion
48 1 Set Rod
49 2 Rotor
50 2 Groove Pin (
3
/32"x
3
/4" Long)
51 2 Cover Gasket
52 8 #6-32 x
1
/
4" Long Fillet Head Machine Screw
53 1 O-Ring #1820-3
54 1 Setting Rod Bushing
55 1 Gear Frame Gasket
56 8 Insert (Rotor)
57 2 O-Ring (For Intermittent Gear Shaft piece #42) (Not shown)
58 2 Groove Pin (
1
/
8"x 1" Long)
61 1 Finger Base
62 8 Right Hand Finger Assembly
63 8 Left Hand Finger Assembly
64 16 #10-32 x 1" Long Hex Head Machine Screw
65 32 #10 Lockwasher
66 32 #10-32 Hex Nut
67 24 #10 Washer
68 2 #
1
/4-20 x
7
/8" Long Fillet Head Cap Screw
69 2
1
/4" Internal Tooth Lockwasher
