Limitorque SMB-5T - Figure 7.12 - SMB-0 through SMB-4 and 4 T Exploded View

SMB/SB Installation and Maintenance Manual 140-11000 • July 2003 7-25
Flow Control Division
Limitorque Actuation Systems
Figure 7.12 – SMB-0 through SMB-4 and 4T Exploded View
To declutch
Position
indicator
gearing
H.W operation
position
Motor operation
position
Position
indicator
gearing
Local dial
indicator
Slidewire Transmitter
Set
screw
Lockwire
SMB-0 pinion
08-408-0001-4
