SMB/SB Installation and Maintenance Manual 140-11000 • July 2003 8-7
Flow Control Division
Limitorque Actuation Systems
Table 8.2 – SB-0 Parts List
Piece Quantity Description
21Housing
31Spring Housing
61Geared Limit Switch Compartment Cover
11 1 Drive Sleeve
16 1 Worm Gear
20 1 Stem Nut
26 1 Seal Retainer Plate
28 1 Spacer
66 1 Spring Housing Gasket
69 1 Limit Switch Compartment Cover Gasket
74 1 Bearing Shim Set
75 1 Bearing Cone
76 1 Bearing Cup
77 1 Bearing Cone
78 1 Bearing Cup
93 1 Quad Ring
94 1 O-Ring
98 1 Grease Fitting
104 1 Torque Switch
106 1 Thrust Sleeve Bearing Cartridge
107 1 Thrust Sleeve
108 1 Belleville Spring Shim
109 5 Belleville Springs
110 1 Indicator Dial Plate
111 1 Indicator Shaft
112 1 Indicator Lever
113 1 Indicator Spring
114 1 Indicator Pointer
116 1 Bearing Cup
117 1 O-Ring
118 1 O-Ring
119 1 O-Ring
163 1 Plug
168 2 Roll Pin
169 8 Socket Head Cap Screw
171 1 Socket Head Set Screw
172 1 O-Ring
180 4 Drive Screw
203 8 Lockwasher
