S520
Connections
6: HB through
3: Motor supply
4: HB through
S330
Connections
6: Mains through 1
Female connection top entry,
male connection side entry
3: Motor supply
4: Mains through 1
Female connection top entry,
male connection side entry
S340
Connections
6: Mains through 2
Male connection top entry,
female connection side entry
3: Motor supply
4: Mains through 2
Male connection top entry,
female connection side entry
