Page 93 of 192
S430
Connections
6: Mains through 1
Female connection top entry,
male connection side entry
3: Motor supply
4: Mains through 1
Female connection top entry,
male connection side entry
S440
Connections
6: Mains through 2
Male connection top entry,
female connection side entry
3: Motor supply
4: Mains through 2
Male connection top entry,
female connection side entry
S530
Connections
6: Mains through 1
Female connection top entry,
male connection side entry
3: Motor supply
4: Mains through 1
Female connection top entry,
male connection side entry
