2.40 Get Pulse Input
■ Class Get (in)
■ Identifier lt_GetPulseInput
■ Hex Value 0xA9
■ Call LT360LIB_CmdValue(Handle, lt_GetPulseInput, RtnStr);
■ Returns 'OFF' or 'ON'
Description
This command returns the status for the Pulse Input BNC function of the
LT360. The returned string value is either OFF or ON.
This parameter enables the TTL Pulse Input feature. When PulseInput is set
ON, the LT360 will respond to TTL pulses at the BNC connector. When it is
set OFF, it will ignore any pulses.
Each pulse will trigger a step. The width of the pulse should be at least
10uSec, and the triggering can be set on the rising or falling edge. Any
pulses which occur while the LT360 is moving will be ignored.
If you are not using the TTL pulse input, it is probably best to keep this
feature OFF to prevent false triggering due to any noise pickup at the open
connector.
