D9U001PPB-0101 73/106
10.17 Instrument tray
This flat, stainless-steel tray is in most cases
used for tools necessary in post-delivery su-
tures. The tray can be parked below the seat
section and, where required, you can place this
tray onto existing and deeper trays (4,5l and 8l).
10.18 Protractor of the seat part, Protractor of the back part
WARNING!
The protractor is only for information!
It is used to inform about the inclination of the back or the seat part of the delivery bed
10.19 Bracket for oxygen bottles
WARNING!
Maximum load 10 kg (22 lb)!
WARNING!
The holder cannot be used on the bed on the right side of the DIN rail with
respect to the patient sitting on the bed!
WARNING!
It can be used on the left side of the patient while sitting on the delivery bed.
There is a risk of collision when positioning with the leg rest!
