Linksys LAPAC1750PRO User Manual

29
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
LAN
This section describes how to manage the access point and contains the
following subsections:
• VLAN and IPv4 Address
• IPv6 Address
• IPv6 Tunnel
The configuration pages for the features in this section are located under the
Manage heading on the Administration Web UI.
VLAN and IPv4 Address
The default wired interface settings, which include DHCP and VLAN information,
might not work for all networks.
By default, the DHCP client on the access point automatically broadcasts
requests for network information. If you want to use a static IP address, you
must disable the DHCP client and manually configure the IP address and other
network information.
The management VLAN is VLAN 1 by default. This VLAN is also the default
untagged VLAN. If you already have a management VLAN configured on
your network with a different VLAN ID, you must change the VLAN ID of the
management VLAN on the AP.
To configure the LAN settings, click the Configuration > LAN > VLAN and IPv4
Address tab.
Figure 22: VLAN and IPv4 Address
The following table describes the fields to view or configure on the VLAN and
IPv4 Address page.
Table 25: VLAN and IPv4 Address
Field Description
MAC Address Shows the MAC address for the LAN interface for the
Ethernet port on this AP. This is a read-only field that you
cannot change.
Management
VLAN ID
The management VLAN is the VLAN associated with the IP
address you use to access the AP. The default management
VLAN ID is “1.”
Provide a number between 1 and 4094 for the management
VLAN ID.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
