Linksys LAPAC1750PRO User Manual

86
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Write Views Select the write access to management objects (MIBs) for
the group:
• write-all — The group can create, alter, and delete
MIBs.
• write-none — The group is not allowed to create, alter,
or delete MIBS.
Read Views Select the read access to management objects (MIBs) for
the group:
• view-all — The group is allowed to view and read all
MIBs.
• view-none — The group cannot view or read MIBs.
SNMP Groups This field shows the default groups and the groups that
have been defined on the AP.
Use the buttons on the page to perform the following tasks:
• Add: Add the new group to the SNMP Groups table.
• Remove: Remove the selected group from the SNMP Group table.
• Save: Apply and save the changed SNMP group settings.
Targets
An SNMP target receives trap messages and forwards them to the SNMP
manager. Inform messages are not supported. Each target is associated with
target IP address, UDP port, and SNMP user name.
NOTE:
Required SNMP user configuration ”Users” on page 87 should be
completed before configuring SNMP targets.
NOTE:
The access point supports a maximum of eight targets.
To display the SNMP Targets Configuration page, click the Configuration >
SNMP > Targets tab.
Figure 45: SNMP Targets

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
