Linksys LAPAC1750PRO User Manual

85
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Groups
SNMP groups allow you to combine users into groups of different authorization
and access privileges. Each group is associated with one of three security levels:
• noAuthNoPriv
• authNoPriv
• authPriv
Read and/or write access to management objects (MIBs) for each group is
controlled by associating a MIB view to a group for read and write access,
separately.
By default, the access point has two groups:
• RO — A read-only group with no authentication and no data encryption.
No security is provided by this group. By default, users of this group will
have read access to the default all MIB view, which can be modified by the
user.
• RW — A read/write group using authentication and data encryption. Users
in this group use an MD5 key/password for authentication and a DES key/
password for encryption. Both the MD5 and DES key/passwords must be
defined. By default, users of this group will have read and write access to
default all MIB view, which can be modified by the user.
NOTE:
The default groups RO and RW cannot be deleted.
NOTE:
The Access Point supports a maximum of 8 groups.
To define additional groups, navigate to the Configuration > SNMP > Groups
page and configure the settings that Table 52 describes.
Figure 44: SNMP Groups
Table 52: SNMP Groups
Field Description
Name Specify a name to use to identify the group. The default
group names are RW and RO.
Group names can contain up to 32 alphanumeric
characters.
Security Level Select one of the following security levels for the group:
• noAuthentication-noPrivacy — No authentication and
no data encryption (no security).
• Authentication-noPrivacy — Authentication, but no
data encryption. With this security level, users send
SNMP messages that use an MD5 key/password
for authentication, but not a DES key/password for
encryption.
• Authentication-Privacy — Authentication and data
encryption. With this security level, users send an
MD5 key/password for authentication and a DES key/
password for encryption.
For groups that require authentication, encryption, or
both, you must define the MD5 and DES key/passwords on
the SNMP Users page.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
