Linksys LAPAC1750PRO User Manual

92
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Global RADIUS If the Verification Mode is RADIUS, select to specify
that the default Global RADIUS server list is used to
authenticating clients. If you want the CP feature to use
a different set of RADIUS servers, clear this setting and
configure the servers in the fields on this page.
RADIUS
Accounting
Enables tracking and measuring the resources a
particular user has consumed, such as system time and
amount of data transmitted and received.
RADIUS IP
Network
Specify whether the RADIUS IP addresses are IPv4 or IPv6
RADIUS server addresses.
RADIUS IP The IPv4 or IPv6 address for the primary RADIUS server
for this VAP. The IPv4 address should be in a form similar
to xxx.xxx.xxx.xxx (192.0.2.10). The IPv6 address should
be in a form similar to xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:
xxxx (2001:DB8::CAD5:7D91).
When the first wireless client tries to authenticate with
a VAP, the access point sends an authentication request
to the primary server. If the primary server responds to
the authentication request, the access point continues
to use this RADIUS server as the primary server, and
authentication requests are sent to the address you
specify.
RADIUS Backup
IP 1–3
Up to three IPv4 or IPv6 backup RADIUS server
addresses.
If authentication fails with the primary server, each
configured backup server is tried in sequence.
RADIUS Current Specify which RADIUS server to use to authenticate
clients:
• primary — Use the RADIUS server with the IP address
configured in the RADIUS IP field.
• backupone — Use the RADIUS server with the IP
address configured in the RADIUS Backup IP 1 field.
• backuptwo — Use the RADIUS server with the IP
address configured in the RADIUS Backup IP 2 field.
• backupthree — Use the RADIUS server with the IP
address configured in the RADIUS Backup IP 3 field.
RADIUS Key The shared secret key that the access point uses to
authenticate to the primary RADIUS server.
You can use up to 63 standard alphanumeric and special
characters. The key is case sensitive and must match the
key configured on the RADIUS server. The text you enter
will be displayed as “*” characters.
RADIUS Backup
Key 1–3
The RADIUS key associated with the configured backup
RADIUS servers. The server at RADIUS IP Address-1 uses
RADIUS Key-1, RADIUS IP Address-2 uses RADIUS Key-2,
and so on.
Locale Count The number of locales associated with the instance. You
can create and assign up to three different locales to
each CP instance from the Web Customization page.
Delete Instance To delete the current instance, select this option and
click Save.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
