Linksys LAPN300 User Manual

WDS screen
Spanning Tree (Recommended if you configure WDS connections)
Spanning Tree When enabled, STP helps prevent switching loops.
WDS Root
Interface
Status
Enable or Disable the WDS Root.
Be sure the following settings on WDS Root device are
determined and configured. The WDS Station must use the
same settings as Root afterwards.
•
IEEE 802.11 Mode
•
Channel Bandwidth
•
Channel (Auto is not recommended)
Note: To change IEEE 802.11 Mode and Channel
settings, go to Wireless

Basic Settings.
To change Channel Bandwidth setting, go to
Wireless

Advanced Settings.
Note: It is highly recommended that static channel is
configured on both APs. Do not use Auto channel
option when you enable WDS, as both APs in a WDS
link must be on the same radio channel. If Auto option
is configured, there is chance two access points run
on different channels and WDS link cannot establish.
Workgroup Bridge and WDS will not work at the same time.
When Workgroup Bridge is enabled, WDS
will be disabled
automatically.
Local SSID Enter name of the WDS Root SSID (used when connected by
WDS Stations).
Local MAC
Address
MAC address of the WDS Root SSID.
Local Channel The channel used by WDS Root SSID. WDS stations must
use same channel as the WDS Root.
Channel can be changed in "Basic Settings" page.
45

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
