Linksys LAPN300 User Manual

Allowed VLAN
List
Enter the list of VLANs accepted by the WDS Root.
When VLAN is enabled, WDS Root receives from WDS
Stations only packets in the V
LAN list. Packets not in the list
will be dropped.
The VLAN list is only applicable when VLAN is enabled.
The VLAN list includes 1 to 16 VLAN IDs separated by ","
such as "100,200,300,400,500,600,700,800".
Security
Settings
Setting can be Disabled, WPA-Personal, WPA2-Personal,
WPA2-Enterprise or WPA/WPA2-Enterprise.
WDS Station
Interface
Status
Enable or disable the WDS Station.
Before configuring a WDS Station, be sure the following
settings of the device are identical to the WDS Root that will
be connected.
•
IEEE 802.11 Mode
•
Channel Bandwidth
•
Channel (Auto is not recommended)
Note: To change IEEE 802.11 Mode and Channel
settings, go to Wireless

Basic Settings.
To change Channel Bandwidth setting, go to
Wireless

Advanced Settings.
Note: It is highly recommended that static channel is
configured on both APs. Do not use Auto channel
option when you enable WDS, as both APs in a WDS
link must be on the same radio channel. If Auto option
is configured, there is chance two access points run
on different channels and WDS link cannot establish.
Workgroup Bridge and WDS will not work at the same time.
When Workgroup Bridge is enabled, WDS
will be disabled
automatically.
Remote SSID Enter the name of the Root’s SSID. Click Site Survey button
and choose from the list. You must do this for WDS Station
to connect to a remote WDS Root.
46

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
