Linksys LAPN300 User Manual

Remote MAC
Address
MAC address of the access point on the other end of the
WDS link. Optional
WDS Station connects to remote WDS Root by matching
SSIDs, When there is more than one remote WDS Root with
the same SSID, the WDS Station can differentiate them by
MAC address.
The format is xx:xx:xx:xx:xx:xx.
VLAN List Enter the list of VLANs that are accepted by the WDS
Station.
When VLAN is enabled, the WDS Station forwards to the
remote WDS Root only packets in the VLAN list. Packets not
in the VLAN list cannot be forwarded to the remote WDS
Root.
The VLAN List is only applicable when VLAN is enabled.
The VLAN list includes 1 to 8 VLAN IDs separated by "," such
as "100,200,300,400,500,600,700,800".
Security Mode The type of encryption t
o use on the WDS link. It must be
same as the access point on the other end of the WDS link.
The options are Disabled
, WPA Personal, WPA2 Personal,
WPA Enterprise or WPA2 Enterprise.
Status Status of the WDS interface. It can be Disabled, Connected
or Not Connected.
47

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
