3.6 Appearance and Dimension
The following figure shows the dimensions of the inverter. The image shown here is for
reference only. The actual product received may differ.
A
B
B
C
Figure 1. Appearance
Position
Designation
A
Battery SOC indicator: Indicates the SOC of the connected battery.
B
Inverter LED indicator: Displays the current working state of the inverter.
C
Nameplate Label: To clearly identify the product, including device model, S/N
(series number), technical data, certifications, etc.,
The following figure shows the dimensions of the inverter.
Figure 2. Dimension
