LNS Alpha 538 - Service Parameters: Bar Feeder Setup

CHAPTER 8: OPERATION 8-13
ALPHA 538/552
Misc: Front rest setup
Use this function to adjust front rest open/closed
positions.
5.8. Service parameters (Password protected, only for trained technician)
Service: Main screen
Main screen
SERVICE: Bar feeder setup
Defines the Bar feeder length and loading position.
SERVICE: Bar feeder setup
Defines the pusher length, the use of extraction
device and the loading cycle configuration.
