CHAPTER 4: ELECTRICS
4-13
1.4 Symbols
Symbol Description Designation
Main disconnect switch
Main circuit
Circuit-breaker
Contactor mains
Transformer
Bridge rectifier
Fuse
Fuse
Servo motor
Hydraulic pump motor
ALPHA ST 320
