CHAPTER 4: ELECTRICS
4-14
Symbol Description Designation
Emergency stop
Safety switch
Indicator lamp
Relay
Valve solenoid
Diode
LED
Select switch
Proximity switch
Limit switch
A
ir pressure switch
Momentary switch
Function switch
