CHAPTER 4: ELECTRICS 4-5
ALPHA ST320 S2
2.2. Power supply
The main power is supplied by the interface cable. Before connecting the interface cable to the lathe,
make sure the power supply meets the interface specifications.
The power supplied to the bar feeder is protected by a breaker (6A max).
2.2.1. Main power switch QS1
ON / OFF switch for the main power.
Make sure it is turned OFF before opening the electrical cabinet.
Power ON
Power OFF
