CHAPTER 1: BASIC NOTIONS 1-5
ALPHA ST320 S2
4. SAFETY DEVICES
4.1. Description
The ALPHA ST320 S2 bar feed system has been designed with a focus on maximum safety during its
handling and complies with all EC requirements.
Safety covers and devices make access to the moving parts of the bar feed system impossible. Safety
switches keep the bar feed system from operating when these protections are open.
The design of the switches, as well as their insertion into the bar feed system, makes it practically
impossible to bypass them.
By pressing the emergency stop button located on the remote control and the HMI, the functions of the
bar feed system and the lathe are immediately stopped.
The LNS company, or its local representative, may not be held responsible for possible
accidents or property damage, whether caused directly or not, by any means whatsoever,
if certain safety devices have not been included.
4.2. Layout of the safety elements on the barfeed system
Designation Description
A Emergency stop push button
B Main access cover
C Front tube / telescopic tube
SQ8 Safety switch of the main access cover
