7-18 CHAPTER 7: GENERAL DESCRIPTION
ALPHA ST320 S2
9. LATHE CONNECTING PARTS (OPTION)
The lathe connecting parts, or simply called connecting parts, are composed of brackets which serve to
connect the lathe spindle and bar feed system. One end of the connecting parts set is always attached to
the lathe spindle. The other end of connecting parts set could be connected either with optional front rest
or simply the front tube / telescope.
The connecting parts design varies with the lathe type and brand. Diagram of connecting parts shipped
with the bar feeder was placed inside the accessories box. Refer to the diagram to do the installation.
Designation Description
A Connecting parts (optional)
B Second front rest (optional)
C Front tube or telescope (optional)
A
B
