Loepfe YARNMASTER ZENIT+ - System Installation Variants; Installation Variant 1: 24 VDC Power; Installation Variant 2: 90-264 VAC Power; Installation Variant 3: 24 VDC with Faceless Unit

25
Quick Guide YM Zenit
+
Variant 1
External power supply
24 V DC
Variant 3
External power supply
24 V DC
Variant 2
External power supply
90–264 V AC
Central unit (LZE-V)
Power
supply
unit
24 V DC
Spindle
adapter
(SA)
Loepfe 2-wire-bus (L2B)
Loepfe 2-wire-bus (L2B)
Sensing head cable
Sensing head (TK)
22 Installation
Spindle
computer
or
All cable connections are pluggable.
Central unit
(LZE-V Faceless)
LAN connection (crossover cable)
