Quick Guide YM Zenit
+
Marking Type Description
Microswitch
(Power ON/OFF)
LED green Tap
< 1 second
Switch to standby mode
controlled by operating
system
(LED becomes orange)
LED green Press
> 1 second
Only in emergencies!
Forced, uncontrolled switch
to standby mode
(LED becomes orange)
Unsaved data are lost!
LED
orange
Tap
< 1 second
Start
(LED becomes green)
LAN 1 RJ45 Dedicated connection for LZE-V Faceless
IP: 192.168.1.200 (Default)
LAN 2 RJ45 Connection for network IP: DHCP (Default)
USB 2.0 USB port
Display port (HDMI) DP, maximum resolution 1600 x 1200
COM 1 Sub-D
9-pole connector
RS 485
COM 2 Sub-D
9-pole connector
RS 232
