3. Display
3 Display
The CANplus
®
display is a robust, sunlight viewable 4.3” WQVGA color display with five (5) integrated
backlit display buttons and eight (8) large control buttons housed in a rugged, water-tight IP66 rated
enclosure. The five display keys simplify and enhance the user interface by providing positive tactile
feedback when pressed. The display can show virtually any SAE J1939 parameter reported by
the ECU, including RPM, engine temperature, oil pressure, and diagnostic codes. It can be easily
configured to customer preference, including gauge type (analog or digital), gauge arrangements,
gauge size, units, and language.
Different software versions may have slightly different displays.
LOFA document No. 463-3002-59 Page 5
