3. Display
Input / Output Setup
• Outputs
– Output Events
*
Alarm Output
*
At Speed Output
– Aux Out 1-4, Low Side Out 11-14, High Side Out 1-2
*
Armed When
· Always, Never, Autostart, Manual Start
*
Engine Condition
· Always, Stopped, Running
*
Active When
*
Running Ignore Delay (s)
*
Enable Delay (s)
*
Disable Delay (s)
• Inputs
– Event Manager
*
Oil Pressure
*
Coolant Temp
*
Fuel Level
*
Battery Voltage
*
Engine Speed
– Aux Switch 1-6
*
Armed When
· Always, Never, Autostart, Manual Start
*
Engine Condition
· Always, Stopped, Running
*
Switch Type
*
Engine Stop
· Controlled Stop, Immediate Stop, Go to Run, Derate
*
Running Ignore Delay (s)
*
Enable Delay (s)
*
Disable Delay (s)
*
SPN
*
FMI
*
LED Select
· Red, Amber
*
LED Flash Rate
· Slow, Fast, Solid
