Logan L-A846-ND - Audio Configuration; Audio Settings Overview

User Manual
50/183
(kbps)
Close
QCIF(200kb
ps)
CIF(200kbp
s)
The more kbps, the higher image quality, the more network source that
will be took up
Fluenc
y
High/Middl
e/low
The more fluency, the higher image quality, the more network source
that will be took up
Please take compression frame rate in parameter form for reference
Note：Default fluency “low”，support 14 D1 playback
Fluency “Close”， support 16 D1 playback
Fluency “High”， support only 12 D1 playback
Steps：
1. Modify“Resolution”No/QCIF/CIF；
2. Modify“kbps”；
3. Modify” Fluency” High/Middle/low
Note：【 Copy】,other channels can have same setting
4. Click【Apply】or【ok】
4.3.3 Audio setting
Function position：Channel| Audio setting
Function introduction： 1.Audio monitoring：Hear channel sound locally
2.Audio compression：Audio/video record, network monitoring. Remote view.
