Logan L-A846-ND - External Alarm Device Setup; Alarm Device Configuration

User Manual
66/183
◆Output Module: It will open alarm for the relative device (normal close)
2.Click【ok】,save setting
Step 3：Detect Alarm setting
1. Disconnected with the selected channel
2. Selected alarm out parameter setting work normally
3. Top menu will popup alarm coin, and record log at same time
4.5.3 Alarm device
Function position：System setup| Alarm| Alarm device
Function introduction：When touch alarm device, it will send alarm out.
Step 1：Choose “Alarm output”
Click【set】
