G120F/G160F/G200F Part II Description of maintenance
- 21 -
5. Troubleshooting for hard electric starting
Combination switch is open or
faulty
Fuse melted
Starter solenoid faulty
Starter motor faulty
Battery faulty
Battery faulty
Charging coil faulty
Star
ter motor
doesn’t rotate
Battery is unable to
be charged
Inspect P33 (4-2)
Replace
Inspect P40 (4-5)
Inspect P40 (4-5)
Inspect P63 (4-10)
Inspect P63 (4-10)
Inspect P40 (4-5)
