G120F/G160F/G200F Part IV Disassembly and maintenance
- 63 -
4-10. Battery (optional)
Use a battery rated at 12V, 18AH or more.
Do not reverse polarity. Serious damage to the generator
and/or battery may occur.
Check the electrolyte level to be sure that it is between
the marks on the case.
If the level is below the lower mark, remove the caps and
add distilled water to bring the electrolyte level to
the upper mark. The cells should be equally full.
·A battery can explode if you do not follow the correct procedure, seriously injuring anyone
nearby. Always keep spark, flame and flammable materials away.
·Battery gases are explosive, don’t smoke near it and keep spark and flame away. When charging
the battery, keep good ventilation.
Connecting to the starter motor:
Take care not to reverse the polarity or shortcircuiting
will occur.
Normally connect the starter cable to the battery
positive (+) before connecting the battery negative (-).
1) Connect one end of the battery’s positive cable to
the starter solenoid’s terminal.
2) Connect one end of the battery’s negative cable to
a bolt on the engine frame.
3) Connect the other end of the battery’s positive cable
to the positive terminal of the battery.
4) Connect the other end of the battery’s negative cable to the negative terminal of the
battery.
