G120F/G160F/G200F Part IV Disassembly and maintenance
- 62 -
3. Inspection
1) Clutch friction disc
Standard Service limit
3.5mm
3.0mm
2) Clutch plate
Check the clutch plate warpage on a flat plate using
a feeler gauge.
