G120F/G160F/G200F Part III Maintenance
- 26 -
6) Place the foam air filter element over the paper element, and reinstall the assembled air filter.
Be sure the gasket is in place beneath the air filter; then tighten the wing nut securely.
7) Install the air cleaner cover and tighten the wing nut securely.
2. Oil batch air cleaner
1) Remove wing nut, air cleaner cover and cap, and take out element.
2) Wash the element in a solution of household detergent and warm water, then rinse
thoroughly, or wash in
non-flammable or high flash
point solvent. Allow the
element to dry thoroughly.
Soak the air filter element in
clean engine oil and squeeze
out the excess oil.
3) Rinse air cleaner cover and
cap in warm water with
detergent and allow them to dry
thoroughly.
4) Empty the used oil from the
air cleaner case and wash out any accumulated dirt with nonflammable solvent, and dry the
case.
5) Fill the air cleaner case to the OIL LEVEL mark with the same oil that is recommended for the
engine. Oil capacity: 60 cc.
6) Reinstall the air cleaner parts and tighten the wing nut securely.
3-5 Muffler
Carbon will deposit on muffler after a long period of use,
and severely affect the exhaust system. In order to ensure
better performance of the exhaust system, we normally
have to remove carbon deposit from the muffler.
For removing the carbon deposit, we can gently knock the
muffler with a hand hammer, and use compressed air to
blow it.
If the muffler has water drop deposit, or is severely eroded,
which causes higher exhaust noise, it shall be replaced with a new one.
Wing nut
