Lopi Cape Cod - Chimney Termination Requirements; Outside Air Requirements

12 Stove Installation (for qualified installers only)
© Travis Industries 100-01282_000 4111128
Chimney Termination Requirements
• Must have an approved cap (to prevent water from entering)
• Must not be located where it will become plugged by snow or other material
• Must terminate at least 3' (914mm) above the roof and
at least 2' (610mm) above any portion of the
roof within 10' (3.048M) (see Figure 5)
Figure 5
Outside Air Requirements
• Required for mobile homes and in certain localities (check with local building official)
• Must not be drawn from an enclosed space (garage, unventilated crawl space)
• Requires a 3” duct that attaches to the bottom of the stove (see “a” and “b” below).
• Outside air duct must have a rodent screen and rain hood (“c”).
• The Travis Industries Outside Air Kit (sku 99200139) includes all the above components.
Figure 6
S
lanted Roofs
F
lat Roofs




Chimney must
extend 3'
above the roof

Chimney must extend 2'
above any portion of the roof
within 10' of the chimney



Chimney must
extend 3'
above the roof
Chimney must extend 2'
above any portion of the roof
within 10' of the chimney





a
b
c
