Lopi Cape Cod - Features and Specifications; Installation Options; Heating Specifications; Dimensions

6 Features & Specifications
© Travis Industries 100-01282_000 4111128
Installation Options
• Freestanding
• Freestanding in an Alcove
• Freestanding in a Mobile Home
• Optional GreenStart Igniter
• Optional High-Tech Blower
Features
• EPA Phase II Approved
• 3.0 Cubic Foot (0.278 M
2
) Firebox Volume
• Single Operating Control
• Accepts Logs Up to 24" (610mm) Long
• Cast Iron Construction
• Heavy Duty Refractory Firebrick
Heating Specifications
Approximate Maximum Heating Capacity (in square feet)* up to 2,500 (232 M
2
)
Maximum BTUs per Hour (Cord Wood Calculation) 86,000
Maximum Burn Time Up to 12 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside
temperature. It is also affected by the quality and moisture level of the fuel.
Dimensions
Figure 1
(a) Side, rear and corner clearances are measured from the stove top.
(b) Rubber-Tipped Leveling Bolts (at each corner).
Emissions
0.45 Grams per Hour (EPA Phase II Approved).
Weight: 600 Lbs. (267 Kg)
3-1/4"
83mm
32-1/4"
821mm
19-3/4"
501mm
2"
51mm
a
b
35"
889mm
