28 Maintaining Your Appliance
© Travis Industries 100-01282_000 4111128
Monthly Maintenance (while appliance is in use)
Make sure the appliance has fully cooled prior to conducting service.
Door and Glass Inspection
The door must form an air-tight seal to the firebox for the stove to work correctly. Inspect the door gasket
to make sure it forms an air-tight seal to the firebox.
The door latch should pull the door against the face of the stove (but not so tight as to not allow full
handle rotation). If the latch requires adjustment, follow the directions below.
Door Adjustment
The door latch should hold the door tightly against the stove, while allowing the handle to rotate fully. If
the latch requires adjusting, follow the directions below.
Loosen the bottom nut with a 7/16” wrench
(see arrow to the right). Tap the bottom nut
inwards, moving the door catch inwards.
Tighten the nut and test operation. You may
need to repeat this process, either moving
the nut inwards or outwards, until the door
catch is in the correct position.
Door Handle
Door Removal
NOTE: It will be helpful to have another person hold the door in place while removing the door.
To remove the door, open the door, then
remove the four hex screws securing the
hinges and remove the door and hinges as
one assembly.
Screw locations
Severely frayed or thread-bare
gasket should be replaced.
Use RTV high
temperature 600° silicone
to adhere loose gasket.
If the glass is damaged, replace
it - see “Replacement Parts” for
details.
High-Temperature
anti-sieze may be
used on the door
hinges to eliminate
squeaks.
