Operating Your Appliance 19
© Travis Industries 100-01282_000 4111128
Opening the Door
The door becomes hot during use. Use a glove to open the door if the handle is hot.
Do not operate this stove with the door open. A fire hazard will result.
To prevent smoke from entering the room, open the air control and bypass (see instructions below)
before opening the door. You can also open the door a small amount and let air enter the firebox to
equalize the pressure, and then open the door fully.
Bypass Operation
The bypass controls the flow of smoke inside the heater. When pulled out, smoke goes directly up the
flue, creating more draft. When pushed in, the smoke goes around the baffle, utilizing the secondary
combustion and making the heater more efficient.
• When re-loading, pull the bypass out.
• During normal operation, push the bypass in.
Bypass Pushed In
Used for normal operation
Bypass Pulled Out
Used for starting and re-loading
Use the included pull tool
to operate the bypass rod
