Technical data
- 24 -
11.18909.1550.1-08
17 Technical data
Technical data
1)
Units
X 350
X 350 VRD RU
TIG welding
Welding range min - max
A
10...350
V
10,4...24,0
Idle voltage (peak value in accordance
with EN 60974-1)
V/DC
< 113 –
Idle voltage VRD (in accordance with
ГОСТ 12.2 007.8)
V/DC – 12
Current setting
Innitely
variable
Slope characteristic
falling
Welding current at ED 100% A
250
Welding current at ED 60% A
300
ED at maximum welding current %
40
Current consumption I
1
(for ED 100%) A
12,3
Current consumption I
1
(for ED 60%) A
15,7
Current consumption I
1
max A
19,6
Maximum effective mains current (I
1eff
) A
12,4
Power consumption S
1
(for ED 100%) kVA
8,5
Power consumption S
1
(for ED 60%) kVA
10,9
Power consumption S
1 max
kVA
13,6
Electrode welding
Welding range min - max
A
10...350
V
20,4...34,0
Idle voltage (peak value in accordance
with EN 60974-1)
V/DC
< 113 –
Idle voltage VRD (in accordance with
ГОСТ 12.2 007.8)
V/DC – 12
Current setting
Innitely
variable
Slope characteristic
falling
Welding current at ED 100% A
230
Welding current at ED 60% A
280
ED at maximum welding current %
35
Current consumption I
1
(for ED 100%) A
16,0
Current consumption I
1
(for ED 60%) A
20,7
Current consumption I
1
max A
27,5
Maximum effective mains current (I 1eff ) A
16,3
Power consumption S
1
(for ED 100%) kVA
11,1
Power consumption S
1
(for ED 60%) kVA
14,3
Power consumption S
1
max kVA
19,1
Weldable electrodes mm
1,5...8,0
Technical data
1)
Units
X 350
X 350 VRD RU
MIG welding
Welding range min - max
A
10...350
V
14,5...31,5
Idle voltage (peak value in accordance
with EN 60974-1)
V/DC
< 113
Mains
Mains voltage V
400 / 3~
Mains frequency Hz
50...60
Positive mains tolerance %
25
Negative mains tolerance %
30
Negative mains tolerance, short-time %
40
Mains connection mm²
4 x 2,5
Mains plug
CEE 32
Current consumption I
1 no-load
A
0,2
Mains fuse slow-response TIG/EL A
25
Power factor cos φ I
2
max cos φ
0,99
Max. permissible system impedance
Zmax in acc. with IEC 61000-3-11/-12
mΩ
44
Recommended generator perform-
ance
kVA
–
Machine
Protection class IP
34
Insulation class
F
Cooling method
F
Noise emission db(A)
<70
Standard
EN 60974-1
Designation
CE, S
Dimensions and weights
Dimensions power source (LxWxH) mm
515 x 185 x
400
Weight of power source kg
18,6
Tab. 9: Technical data
1)
ED = Switch-on duration
1)
measured at 40°C ambient temperature
