Explanation of symbols
- 4 -
11.18909.1550.1-08
1 Mains cable holder
2 Transportation belt
3 Handle (hoisting point)
4 Control panel
5 Accessories belt
6 Main switch
7 Remote control socket
8 Connection socket torch/electrode holder/compo-
nent guide
9 Mains cable
The carrying strap is exclusively for the
transport by a person.
Some depicted or described accessories
are not included in the scope of delivery.
Subject to change.
i
1 Machine elements
4
5
6
7
8
8
9
2 31
Abb. 1: Machine elements
2 Explanation of symbols
2.1 Meaning of the symbols in the opera-
tion manual
Danger of physical injury or death!
If the danger warnings are disregarded,
this can cause slight or severe injuries or
even death.
Danger of property damage!
Disregarding danger warnings can cause
damage to workpieces, tools, and equip-
ment.
General note.
Designates useful information about the
product and equipment.
2.2 Meaning of the symbols on the
machine
Danger!
Read the user information in the operation
manual.
Disconnect the mains plug!
Pull out the mains plug before opening the
housing.
