Lorex DV700 Series User Manual

DV700 Series System Specifications
24
Network Interface 10/100-Base-TX, RJ-45
Network Speed Control 48Kb ~ 4096Kb/sec. per camera
General
Power Consumption Approx. 10 watts (No HDD Installed)
Supply Voltage DV704 / DV708: 100VAC-240VAC, 12VDC, 2A,
50/60Hz
DV716: 100VAC-240VAC, 12VDC, 3A, 50/60Hz
Unit Dimensions (W x D x H) DV704 / DV708 / DV716:
12.8” x 10.0” x 2.2”
325mm x 255mm x 55mm
Unit Weight
DV704 / DV708 / DV716: 3.3lbs / 1.5kg
Operating Temperature 32° ~ 104° F / 0° ~ 40° C
Humidity 10 ~ 90% RH
Recording Resolution (Pixels) & Speed (FPS - Frames per second)
Model
FPS (NTSC/PAL)
720p
1280x720
1080p
1920x1080
DV704
Total 120/100 60/48
Per channel 30/25 15/12
DV708
Total 240/200 120/96
Per channel 30/25 15/12
DV716
Total 480/400 240/192
Per channel 30/25 15/12
As our products are subject to continuous improvement, Lorex Corporation and its subsid-
iaries reserve the right to modify product design, specifications, and prices without notice
and without incurring any obligation. E&OE
#LX400060; r.30328/30328; en-US
