SPECIFICATION
OM 0467SB-A [9]
Features and Specifications
39002748 – LW3150
Type
Counter clockwise
Overall width 50"
Overall height (without chute) 21"
Overall height (with chute) 46"
Overall length (without female hitch) 22 1/2"
Overall length (with female hitch) 30 3/4"
Working width 49 3/4"
Working height 20"
Housing thickness 14 Ga.
Side plate thickness 11 Ga.
Thickness of the drum back plate 14 Ga.
Thickness of the drum contour 12 Ga.
Number of stages 2
Drive Driveline
Impeller drive Chain #40
Driving sprocket 40C11
Driven sprocket 40B32
Auger drive Worm gearbox - ratio 5:1
Auger diameter 12 3/4"
Auger pitch 15"
Impeller width 15 3/4"
Number of impeller blades 4
Chute position Right
Chute rotation Manual
Adjustable deflector Yes
Adjustable skid shoes Yes
Replaceable cutting edge Yes
Cutting edge angle 20°
Number of shearbolts on au
er 2
Number of shearbolt on impeller 1
Hitch system Quick-Hitch
Approximate shipping weight 287 lbs
