MAINTENANCE
OM 0467SB-A [26]
Auger Repositioning
(Figure 16)
After shear bolt breakage on one of the
augers, make sure to reposition the augers
as shown on the figure below.
Drive Chain Tension Adjustment
(Figure 17)
IMPORTANT
: The chain must be adjusted after
the first 8 hours of operation and every 24 hours
of operation after that.
Remove the driveline guard. Loosen the four bolts
securing the reduction box to the snowblower.
Adjust chain to obtain a deflection of between 1/16"
and 1/8". Tighten the four bolts of the reduction box
and reinstall the driveline guard.
Figure 16
1/16"
to
1/8"
1/16"to
1/8"
Figure 17
