LS tractor LW3150 - Reduction Box

PARTS
OM 0467SB-A [32]
REDUCTION BOX
REF DESCRIPTION QTY PART#
1 REDUCTION BOX ASS'Y INC. BEARINGS 1 657353
2 DRIVE SHAFT WITH SPROCKET (H40C11) 1 657250
3 BALL BEARING WITH SETSCREW 2 665494
4 TRIANGULAR BEARING FLANGE - 3 HOLES 4 656589
5 CARRIAGE BOLT 5/16"NC X 5/8" GR. 5 PTD 6 0300001
6 LOCKWASHER 5/16" 10 1200003
7 HEX. NUT 5/16" 10 0900002
8 CARRIAGE BOLT 5/16"NC X 3/4" GR. 5 PTD 4 0300002
9 FLAT WASHER 3/8" HOLE 4 1400003
10 SPROCKET (40B32) (INCL. SETSCREW) 1 656543
11 -
A
LLEN SETSCREW 5/16"NC X 5/16" 2 0500009
12 CHAIN #40 X 38 LINKS INCL. CONNECTING LINK 1 656570
13 - CONNECTING LINK 1 656178
14 DRIVELINE SHIELD 1 669613
15 BOLT HEX 1/4"NC X 2 1/4 GR.5 PTD" 1 0100010
16 NYLON INSERT NUT 1/4"NC 1 1000003
17 KE
Y
1/4" X 1/4" X 1 1/4" 2 654643
18
A
LLEN SET SCREW 3/8"NC X 1/4 GR5 BLACK 1 0500030
19 REDUCTION BOX 1 657355
20 SERRATED FLANGE BOLT 5/16NC X 1/2", GR.5 PTD 2 0200065
FIG: RAD17XXXXX
