LS tractor R4047H User Manual

R4041 /
R4041 EZ
R4041H
R4047 /
R4047 EZ
R4047H
TRANSMISSION
Forward / Reverse
Synchro-shuttle
type
HST
Synchro-shuttle
type
HST
Gear
type
Main gear
Helical /
Synchromesh
HST
Helical /
Synchromesh
HST
Range gear Spur / Constant mesh
Creeper gear N/A
Gear
stage
Main gear 4 N/A 4 N/A
Range gear 4 3 4 3
Creeper gear N/A
DIFFERENT
IAL LOCK
Gear type Spiral bevel
Operation Mechanical foot pedal
PTO
Type Independent PTO with wet multi-disks / GSP (option)
No. of speed 3 stage / 1 stage (option)
PTO / Engine
1 stage : 540 rpm / 2409 rpm
2 stage : 750 rpm / 2375 rpm
3 stage : 1000 rpm / 2381 rpm
HYDRAULIC LIFT
3 Point linkage CAT1
Draft load detection Upper link (option)
Lowering speed
control and cylinder
Down speed control valve
6
6 6
6 - 3
HYDRAULIC LIFT
control and cylinder
fixing device
Down speed control valve
Pump Gear type, Engine drive
Rated flow
31.2LPM
(8.2GPM)
System pressure 16.7MPa (2422psi)
Lift capacity
(lower link end)
1209 kgf (2665 lbf)
REMOTE
CONTROL
No. of spool 2 (option : 1 or 3)
Valve operation
mode
Double acting , Spring return type

LS tractor R4047H Specifications

General

Brand	LS tractor
Model	R4047H
Category	Tractor
Language	English
