(5) Joystick lever (if fitted)
※
Remote joystick lever helps to operate front
loader comfortably.
When connecting hydraulic hoses, comply with the
instruction as below.
►
loader down - opening
①
►
loader up - opening
②
►
bucket up - opening
③
►
bucket dump - opening
④
The standard of hydraulic opening is PS3/8”.
Use the adapter for hydraulic connection.
Joystick can be operated at 4 directions as shown
If you move joystick diagonally, loader and bucket
shall be operated at the same time. Then, small
loads move first.
When you want to float bucket, lower the loader
and push forward the lever at floating position.
After finishing work, pull the lever and place it in
neutral position.
▶
To prevent accidents, push and lock the locking lever when you do not use joystick
lever.
▶
When the loader is at the high position, do not place the joystick lever in the floating
