When engine oil is warm, the
impurities can be drained
Notice
①
①①
① Drain Engine oil
Run engine for a few minutes to warm oil
Park the tractor on a level surface.
Remove drain plug of oil pan and drain the oil
completely.
5-8. Every 300 hour check
(1) Replacing Engine oil and Filter
Oil filling inlet
②
②②
② Replace Engine oil filter
Clean carefully around the filter.
Coat clean engine oil on the packing of new filter
and check the packing is placed well in the
groove.
Turn the oil filter counter-clockwise to remove
with filter wrench.
Turn the new filter clockwise to assemble until the
packing makes contact with the mounting surface.
Tighten ¾ to 1 turn more after packing contact.
If the metal is attached to the element of oil filter
to be disassembled, contact your authorized
dealer.
③
③③
③ Fill Engine oil
Tighten the drain plugs. (Tightening torque :
Engine oil gauge
Drain plug
Engine oil filter
5
5 5
5 - 18
Tighten the drain plugs. (Tightening torque :
40± 5 N.m) (29.5± 5 lbs-ft)
Aid engine oil as its capacity and check the oil
level is between “MIN” and “MAX”.
For oil specification, refer to “Lubricants and
Capacity” at the end of this section.
(See page 5-5)
Check any leakage of the engine while running
the engine for several minutes at idle rpm.
Stop the engine. After several minutes later,
check again the oil level is between “MIN” and
“MAX”.
Install the oil gauge.
Close
Open
Packing
To Next Page
