LS tractor R4047H User Manual

(8) Range gear shift lever
 Four stage speed selection is available.
 Range gear shift lever should be operated after
the tractor has stopped completely.
1
11
1
4
44
4
N
NN
N
3
33
3
2
22
2
1
11
1
 Three stage speed selection is available.
 Range gear shift lever should be operated after
the tractor has stopped completely.
HST type
Mechanical type
2
22
2
the tractor has stopped completely.
(9) PTO gear lever (if fitted)
 540 / 750 / 1000 rev/min and neutral (“N”) position
is available.
1
11
1
Notice
▶ Operate range gear shift lever correctly. If operated diagonally, it may cause a
failure.
Range gear
Shift lever
1
11
13
33
3
N
3
3 3
3 - 11
▶ After putting PTO switch in “OFF” and PTO shaft has stopped completely, place the
lever to desired position. (See page 3-6)
▶ If the PTO gear lever is NOT engaged smoothly, lift up and down on implement to
align the drive shaft.
Caution
is available.
 PTO speed selection;
-. Stage 1 : 540rev/min / engine 2409 rev/min
-. Stage 2 : 750rev/min / engine 2375 rev/min
-. Stage 3 : 1000rev/min / engine 2381 rev/min
N
NN
N
3
33
3
2
22
2
