LSIS eXP Series, eXP20-TTA User Manual

Appendix 1 Troubleshooting
App1-12
Object
Error code
Occurrenc
e location
Error message Reason and measure
Type Address
Viewing
device
information
0x03 0x01
XGT
Panel
No project in XGT
Panel.
Now, there is no downloaded project so
you can’t see connection information.
Download the project from XP-Builder.
XGT Panel
Update
0x04 0x01
XGT
Panel
Failed to Start engine.
Please update engine
again.
Because of update error or Flash disk
error, program can’t be executed. If you
can update, redo the above procedure.
If you can’t, contact the near Customer
Service Center.
Switch h05 h01
XGT
Panel
Invalid password.
There is password in the each object.
When editing the project downloaded in
the present device, input the
designated password at the project
property information.
Number
indication
device/
Number
input device
0x06
h01
XGT
Panel
Can't write Data.
Because of communication error, the
value can’t be inputted. Check the
communication status and input again.
h02
XGT
Panel
No input Data.
You tried to input with no value. Input
the value
0x03
XGT
Panel
Exceeded the max
length.
You exceed the maximum length to
input.
0x04
XGT
Panel
Exceeded the
minimum Value.
You exceed the maximum value to
input.
0x05
XGT
Panel
Exceeded the
maximum Value.
You exceed the minimum value to
input.
0x06
XGT
Panel
Invalid at Input Case.
When you input the value, input can’t
be done because of wrong input. Check
the input condition of each object in the
Builder and input again.
Lamp 0x07 None
Character
indication
device/
Character
input device
0x08 None
Message
0x09
None
Clock
0x0A
None
Animation
0x0B
None
Graph
0x0C
None
Window
0x0D
None
Part
0x0E
None
History
alarm
0x0F None
Flow alarm
0x20
None
System
alarm
0x21 None
