Chapter 5 Diagnostics

5-2

5.1 Screen Diagnosis

If you press [Screen] button, screens continuously change into diverse color with buzzer. After all screen for

diagnosis pass. Then, Close button shows up with white ground.

If you press Close button, the initial screen shows up.

[Diagnosis screen]

[Screen diagnosis]

Display Sequence

RED > GREEN > BLUE > BLACK > WHITE>GRAPH
