Chapter 1 General Introduction
Chapter 1 General Introduction
1.1 How to use the Instruction Manual
This instruction manual provides information such as specification, how to use, etc., of the product needed to operate eXP
series of XGT Panel.
The user manual’s configuration is as follows.
Sequence Category Contents
Chapter1 General Introduction It describes this manual’s configuration, product’s feature and term.
Chapter2 System Configuration It describes feature and system configuration of each XGT Panel.
Chapter3 Standard Specification It describes XGT Panel’s general and function specification.
Chapter4 System Configuration It describes XGT Panel’s system configuration.
Chapter5 Diagnostics It describes XGT Panel’s self-diagnosis.
Chapter6
Viewing information of
It describes the way on connection status information of PLC which is
connected with XGT Panel.
It describes the way to execute the project by using USB storage
device.
Chapter8 XGT Panel S/W Update It describes the way to update engine at XGT Panel.
Chapter9
Backup files by using
It describes the way to backup recipe, logging and etc. files by using
Chapter10 Installation and Wiring
It describes an installation, wiring and caution for reliability of PLC
It describes inspection category and method for long normal operation
of PLC system.
Chapter12 EMC Standard It describes system configuration for EMC standard.
Appendix 1 Troubleshooting It describes a variety of error contents and measure.
Appendix 2 Dimension It describes the dimension of XGT Panel.
Appendix 3
Warranty and
This manual doesn’t describe connection with XP-Builder and PLC. For their own function, Please refer to the related
manuals.
