LSIS eXP Series, eXP20-TTA User Manual

Chapter 3 Standard Specification
3-3
3.2 Function Standards
eXP Series function standard is as follows.
Item
eXP20-TTA/DC,CERTI
eXP20-TTA/DC eXP30-TTA(B)/DC eXP30-TTE/DC
Display type
TFT color LCD
Screen size 10.9cm(4.3”) 14.2cm(5.6”)
Display Resolution 480 x 272 640 x 480 pixel
Color indication
24-bit Color(16.7M) 16-bit Color(65,535 Color)
Indication degree
Left/Right:60 deg.
Upper:40 deg.
Lower:60 deg.
Backlight
LED Type (Supports backlight auto-off function)
Backlight duration
30,000 hours 20,000 hours
Touch panel
4-Wire Resistive, analog
Audio Output Magnetic buzzer (85dB)
Process
i.MX283(454MHz)
Memory
Flash 128MB (Screen 64MB)
Operating RAM
128KB
Backup RAM 128KB
Backup data Date/Hour data, Logging/Alarm/Recipe data and nonvolatile device
Battery duration Approx. 3 years (Operating ambient temperature of 50℃)
RTC Time error Approx. 3 sec/1day(Operating ambient temperature of 25℃)
Ethernet
1 channel, IEEE802.1a, 10Base-T/100Base-TX
-
USB Host 1 channel, USB 2.0 Host (mouse, keyboard, printer and USB memory driver is available)
USB Device
- 1 channel, USB 2.0 Device
(for download and upload project)
RS-485, RS-232C
1channel, RS-232C
(DSUB 9/Male Type)
RS-422/485
1channel, RS-422/485
(DSUB 9/Male Type)
Multi-language Up to 12 language simultaneously
Animation
GIF format is available
Recipe available
Data logging
available
Script executor available
Certifications
CE, UL Type4X, KC
CE, UL(cUL), KC
Protection standard IP66 IP65
Dimension (mm)
128x102x32
300 x 200 x 68
Panel cut (mm) 119.0x93.0 156.0 x 123.5
Rated voltage
DC24V
Power consumption (W) 4.6W 7.2W
Weight(Kg)
0.3
0.42
0.39

LSIS eXP Series, eXP20-TTA Specifications

General

Brand	LSIS
Model	eXP Series, eXP20-TTA
Category	Touch Panel
Language	English
