Chapter 6 Viewing Information of PLC Connection Status
6-7
6.8 N:1 Settings
Using N:1 communication, it means communicate number of XGT Panel with single PLC.
[PLC information screen]
[N:1 settings dialog box]
[Dialog box setting options]
Name
Description
Use N:1 Communication
The matter of performing N:1 communication is designated.
N:1 station number
The station number of N:1 communication is input.
Number of XGT Panel
The number of XGT Panel in N:1 communication is input.
Master Holding Time
The master holding time of N:1 communication is input.
Remark
For detail information about the N:1 communication, please refer to the XP-Builder manual.
